Pressure- Temperature- Humidity Scanner Controller

Pressure- Temperature- Humidity Scanner Controller

Product Details:

X

Product Description

Specification

Power supply:

230VAC / 110VAC / 24VDC

Display:

16X2 LCD

Auto/Manual Mode:

Auto mode as per scan time (0-99Sec)
Manual Mode Advance by Keypad.

No. of Inputs

8 / 16 Nos.

Inputs & Ranges

Temperature (PT100 / PT1000) -50 to +150 C
Humidity (4-20mA) -0 to 100%RH
Pressure (4-20mA) -1 to 5Bar, -1 to 10Bar, -1 to 25Bar

No. of Outputs

8 / 16 Relay outputs (1 output for each input)

Output type:

SPDT Relay. Rated current - 5A - 230VAC

Resolution:

Pressure - 0.1 Bar
Temperature - 0.1°C
Humidity - 1 %RH

Enclosure:

IP54

Enclosure Mounting:

Panel mounting

Parameters Displayed:

Pressure (Bar)
Temperature (C)
Humidity (%RH)
Set Points for each channel

LED Indications:

Each Relay Output

Communication:

RS485 Modbus




MANIK ENGINEERS
